Epson EpiqVision Mini EF-22N Full HD Smart Lifestyle Home Projector

The Epson EpiqVision Mini EF-22N home projector is perfect for your home entertainment setup, with its Full HD resolution, 1,000 lumens of equal white and colour brightness, smart function, 5W x 2 speakers that support Dolby Audio^TM, high contrast ratio, laser light source technology, and built-in Google TV^TM and Google Cast.

The latest EpiqVision Mini range comes in 3 colours, blending in yet aesthetically enhancing your home entertainment setup.

The EpiqVision Mini EF-22N combines sleek, smart design with a trendy Metallic Navy colour and metallic finish, enhancing any home decor. Its rounded rear and angular front design creates a streamlined, sophisticated look.

Proprietary 3LCD multi-array laser diode technology creates excellent brightness levels while significantly enhancing black density, resulting in exceptionally bright, clear images. Our technology ensures 1,000 lumens of colour (IDMS-rated) and white (ISO-rated) brightness, with vivid images of up to 150 inches.

Additionally, enjoy up to 20,000 hours thanks to the laser light source life technology⁵ on your projector. That’s more than 10 years of entertainment!

Tailored Home Entertainment Experience

The smart projector comes with built-in Google TV^TMand Google Cast, offering thousands of movies, shows and games from the Google Play Store, including Netflix, YouTube and your favourite applications. Voice command and personalised recommendations means you can spend more time immersed in your movies and less time on searching for your next show to stream.

Enjoy immersive audio with the projector’s built-in 5W x 2 passive radiator speakers. The 60-degree speaker positioning and DSP chip deliver rich, clear sound from any angle.

Projection Technology:

Projection Technology: RGB liquid crystal shutter projection system

Specifications of Main Parts:

LCD:

Panel Size: 0.62-inch
Driving Method: Poly-silicon TFT active matrix
Native Resolution: Full HD 1080p
Pixel Number: 2,073,600 pixels (1920 x 1080) x 3
Aspect Ratio: 16:9
Pixel: Cross stripe

Light Source:

Type: Laser Diode
LD Input Power: 48W
Light Source Life (Normal / Quiet): 20,000hrs / 20,000hrs

Native Resolution:

Full HD (1080p)

Projection Lens:

F-Number: 2.0
Focal Length: 13.9 mm
Zoom Ratio: 1.0-1.82 (Digital Zoom)
Throw Ratio: 1.0-1.81

Brightness:

Colour Light Output: 1,000lm

White Light Output: 1,000lm

Contrast Ratio: Over 5,000,000:1

Connectivity:

USB Interface:

USB Type A: 1 (For USB Storage, Camera, Mic, HID)
USB Type B: 1

Digital Input:

HDMI: 1 (ARC supported, HDCP 2.3)

Audio Input:

Stereo mini jack: 1 (for headphone)

Adjustment Functions:

Image Adjustment:

Light Output:Yes(Max:100%, Min: 50%)
Color Mode: Dynamic, Vivid, Natural, Cinema, Custom

Start-Up Period:

Start-Up Period: Less than 6 seconds

Power:

Power Supply Voltage: 100 – 240 V AC +/- 10%, 50/60 Hz

Internal Speaker(s):

Sound Output: 5W x 2 Passive Radiator Speakers

Weight:

Weight: Approx. 3.0kg

Air Filter:

Maintenance Cycle (Normal / ECO): 5000H

Cool Down Period:

Cool Down Period: Instant off

Fan Noise:

Fan Noise (Normal / Eco): 22dB / 18dB

Screen Size (Projected Distance – Lens to Screen):

Zoom : Wide: 30″ to 150″ [0.6m to 3.4m]

Zoom : Tele: NA

Standard size: 60″ screen @ 1.33m

Dolby Certification (Audio):

Certification: Dolby Audio (Dolby Digital Plus Consumer Decoder)
Input: Streaming, HDMI

Smart Media Player Specification:

Operating System:

Android 11

ROM/RAM: 16GB/2GB

Supported Video Format: up to 1920×1080 60fps, MP4, MKV，MOV， AVI，WMV，M2TS，MPG，MPEG，DAT， VOB，FLV

Audio Format: MP3, AAC, WMA, RM, FLAC, AC-3,E-AC-3

Wireless LAN: Wi-Fi generation name: WiFi-5
Supported Standards and Frequency: IEEE 802.11a (5 GHz),
IEEE 802.11b (2.4 GHz),
IEEE 802.11g (2.4 GHz),
IEEE 802.11n (2.4 GHz and 5 GHz),
IEEE 802.11ac (5 GHz)
Supported security type: WPA2/WPA3 PSK(AES)

Bluetooth: Version: Ver. 5.1
Output: Class 1
Communication distance: Approx. 10m
Supported Profiles: A2DP, AVRCP
Frequency used: 2.4 GHz
Supported codecs: SBC

Certified Smart Media Player Function: VOD Platform: Google TV
Amazon Prime Video: Yes
Netflix; Yes
Voice Assistant: Google assistant

Auto Shape Correction (with TOF&G&Gyro-sensor):

Function: Auto Keystone Correction Horizontal/Vertical/
Roll, Auto Focus, Real-time Correction
Ceiling mount: Supported
Ceiling projection: Supported

Angle:

Horizontal: -20 degrees to +20 degrees
Vertical: -20 degrees to +20 degrees
Distance: 65cm to 221cm
Screen size: 30-inch to 100-inch
Time: Approx. 1 secondDisclaimer: calibration depends on set angle and distance of projector

Obstacle avoidance:

Function: Auto Keystone Correction Horizontal/Vertical/
Roll, Auto Focus, Real-time Correction
Ceiling mount: Supported
Ceiling projection: Supported

Angle:

Horizontal: -20 degrees to +20 degrees
Vertical: -20 degrees to +20 degrees
Roll: -10 degrees to +10 degrees
Distance: 65cm to 221cm
Screen size: 30-inch to 100-inch
Time: Approx. 5 second
Avoidance range: Limited to outside 1/1.35 of projection imageDisclaimer: calibration depends on ambient illumination, distance and set angle of projector

Screen Fit Function:

Angle:

Horizontal: -15 degrees to +15 degrees
Vertical: -15 degrees to +15 degrees
Roll: -5 degrees to +5 degrees
Distance: 65cm to 221cm
Screen size: 30-inch to 100-inch
Time: Approx. 5 secondDisclaimer: calibration depends on ambient illumination, distance and set angle of projector

Smart Eye Protection:

Smart Eye Protection: Yes

Disclaimer: Disabled during automatic shape correction

Power Consumption (220-240V):

LD On (Normal / Quiet, Extended): 103W / 73W

Networked Standby: 2.0W

Energy Saving: 0.5W

Operating Temperature and Altitude:

Operating Altitude:

0m to 3,048m <0 ft to 10,000 ft>
0m to 3,000m <0 ft to 9,843 ft>
Over 1,500m / 4,921 ft: with High Altitude Mode

Operating Temperature:

Low Altitude:
0m/0ft to 2286m/7500ft
5 °C to 35 °C <41 °F to 95 °F>
20% -80% humidity, No condensationHigh Altitude:
Over 2286m / 7500ft
5 °C to 30 °C <41 °F to 86 °F>
20% – 80% humidity, No Condensation

Dimensions (W x H x D):

Dimension Excluding Feet (W x H x D): 236 x 191 x 191 mm

Maximum Dimension (W x H x D): 236 x 193 x 191 mm
