LG webOS UHD Signage
LG 86″ 4K UHD Signage 86UL3Q-E
LG 4K UHD Signage
LG 86″ 4K UHD Signage 86UL3Q–E, powered by LG webOS 6.1
PANEL
-
Screen Size (Inch): 86″ | Panel Technology: ADS | Back Light Type: Direct | Aspect Ratio: 16:9 | Native Resolution: 3,840 x 2,160 (4K UHD)
-
Refresh Rate: 60 Hz | Brightness: 350 nits | Contrast Ratio: 1,200:1 | Dynamic CR: 1,000,000 : 1 | Color Gamut: DCI 80%
-
Viewing Angle (H x V): 178 × 178 | Color Depth (Number of Colors): 1.07 Billion Colors (Advanced 10 bit) | Response Time: 8m (G to G)
-
Surface Treatment (Haze): 1% | Life time: 30,000 Hrs | Operation Hours (Hours/Day): 16 / 7 | Portait / Landscape: Yes / Yes
MECHANICAL SPECIFICATION
-
Bezel Color: Black | Bezel Width: 12.9 mm (Even) | Weight (Head): 31.8 kg | Packed Weight: 42.6 kg
-
Monitor Dimensions (W x H x D): 1,926.6 × 1,098.0 × 60.0 mm (Without IR) | Carton Dimensions (W x H x D): 2,080 × 220 × 1,255 mm
-
Handle: No | VESA Standard Mount Interface: 600 × 400 mm
-
Speaker (Built-in): 10 W × 2
ENVIRONMENT CONDITIONS
-
Operation Temperature: 0 °C to 40 °C | Operation Humidity: 10 % to 80 %
POWER & POWER CONSUMPTION
-
Power Supply: AC 100-240 V ~, 50/60 Hz | Power Type: Built-In Power
-
Typ.: 205 W | Max.: 287 W | Smart Energy Saving (70%): 143.5 W | DPM: 0.5 W | Power off: 0.5 W
-
BTU (British Thermal Unit): 699.489 BTU/Hr (Typ.), 979.284 BTU/Hr (Max.)
CERTIFICATION
-
Safety: CB | EMC: FCC Class “B” / CE | ePEAT(US only): Yes | ERP / Energy Star: No (NewErP) / Yes
-
OPS Type compatible: No | OPS Power Built-in: No
-
Conformal Coating (Power Board): Yes
SOFTWARE COMPATIBILITY
-
SuperSign CMS: Yes | SuperSign Control+: Yes | SuperSign WB: Yes | SuperSign Cloud: Yes | Mobile CMS: Yes | Connected Care: Yes
ACCESSORY
-
Basic Accessory: Remote Controller, Power Cord, Regulation Book, Easy Setup Guide, Warranty Card, Phone to D-Sub9
